FT3DR
2 m/70 cm Dual-Band Handheld

5 W C4FM/FM Dual Band Digital Transceiver

320x240 full color TFT LCD display

1200/9600bps APRS Data Communication








Compact Design and Reliable 5W RF Power Output (Selectable 5W/ 2.5W/ 1W/ 0.3W)

C4FM Digital V/D Mode, Voice FR Mode, Data FR Mode and Conventional FM Mode

700 mW of audio power with C4FM clear and crisp audio quality

Dual Band Simultaneous Receive (V+V/ U+U/ V+U/ U+V)

Built-in Bluetooth Unit enables the easy hands-free operation (NEW!)

Highly visible 320 x 240 dot matrix Full-Color TFT Touch Panel Display

Band Scope Function enables monitoring up to 79 channels centered around the current VFO frequency with high-speed (NEW!)

CAM (Club Channel Activity Monitor) function (NEW!)

System Fusion II compatible such as AMS (Automatic Mode Select), DG-ID (Digital Group ID), and Smart Navigation functions

WiRES-X Portable Digital Node compatible

Built-in 66ch High-Sensitivity GPS Receiver

1200/9600bps APRS Data Communication

Snapshot Feature

Voice Recording function for the received and transmitting voice and audio

Built-in On/Off Timer, Automatic Power Off (APO) and Time-out Timer (TOT)

micro SD Card Slot (up to 32GB)

IPX5 Rating Water Protection

Supplied Accessories
Antenna
7.2 V 2,200 mAh Lithium Ion Battery Pack (SBR-14LI)
Battery Charger (SAD-25)
Belt Clip (SHB-13)
USB Cable
Operating Manual
Specifications
Frequency Ranges:
A(Main) Band RX: 0.5 - 1.8MHz (AM Broadcast)
1.8 - 30MHz (SW Band)
30 - 76MHz (50MHz HAM)
76 - 108MHz (FM Broadcast)
108 - 137MHz (Air Band)
137 - 174MHz (144MHz HAM)
174 - 222MHz (VHF TV)
222 - 420MHz (GEN1)
420 - 470MHz (430MHz HAM)
470 - 800MHz (UHF Band)
800 - 999.90MHz (GEN2, USA Cellular Blocked)
B(Sub) Band RX: 108 - 137MHz (Air Band)
137 - 174MHz (144MHz HAM)
174 - 222MHz (VHF)
222 - 420MHz (GEN1)
420 - 470MHz (430MHz HAM)
470 - 580MHz (UHF Band)
TX: 144 - 148MHz, 430 - 450MHz
Circuit Type: NFM/ AM:Double-Conversion Superheterodyne
FM /AM Radio: Direct-Conversion
Modulation Type: F1D, F2D, F3E, F7W
RF Power Output: 5W/ 2.5W/ 1W/ 0.3W (@ Batteery pack or EXT DC)
Memory Channels: 1256
Waterproof Rating: IPX5
Case Size(W x H x D): 2.44"x 3.94"x 1.28" (62 x 100 x 32.5 mm)w/ SBR-14LI, w/o Knob & Antenna
Weight: 9.95oz (282 g) w/ SBR-14LI and Antenna
